Ultra Fine 98% 0.5um Pocket Air Filter High Temperature Resistant

Brand Name : RS

Model Number : DL

Place of Origin : China

MOQ : 10 Pic

Payment Terms : L/C, T/T, D/A, D/P

Supply Ability : 1000 Piece/Pieces per Month

Delivery Time : 5-8 work days

Packaging Details : One piece in a plastic bag,then in a carton(according to the size of the products) ，or According to customers' requirement

Filtration Grade : Medium Filter

Efficiency : 98% F5-F8

Porosity : 0.5um

Medium Material : Glass Fiber

Max. Running Temperature : 70℃

Weight : 5-8Kg

Frame : ABS plastic

Final resistance : 100-250Pa

Initial pressure drop(Pa) : ≤80

Construction : Bag Filter

Dimension(L*W*H) : Customized Size

Contact Now

Product description

The filter material : F5,F6,F7,F7,F9 glass fiber filter

The frame material :  Aluminum profile / aluminum plate frame / galvanized frame / stainless steel frame
 The glass fiber filter paper is made of 100% glass fiber. Glass fiber is an inorganic
 non-metallic material with excellent performance. It has many advantages. It has good insulation, heat resistance, good corrosion
 resistance and high mechanical strength. However, it has the disadvantages of brittleness, high resistance and poor wear resistance.


  	 		 		 	 	 			Media 			Glass fiber
 			Pocket-type 			Sewing bag,Ultrasonic bag
 			Frame 			Aluminum/Galvanized steel/Stainless steel/Plastic
 			Filter Efficiency(EN779) 			　F5 F6 F7 F8 F9

 			Max. Temperature 			150℃
 			Max. Humidity 			100%


Features:
1. Large filtering area and high dust holding capacity;
2. Large air volume, low resistance and long service life;
3. Suitable for long-term use in environments below 150 ° C


  	 			Actual size
 			Number of bags(p)
 			Air volume
(m³/h)
 			Initial resistance (Pa)
 			Final Resistance
(Pa)

 			F6
 			F7
 			F8


 			289x595x381
 			3
 			1070
 			80
 			125
 			130







2.5 times the initial resistance

 			6
 			1700
 			80
 			125
 			130


 			289x595x500
 			3
 			1700
 			70
 			105
 			110

 			6
 			2130
 			70
 			105
 			110


285x595x762
 			3
 			1700
 			60
 			85
 			90

 			6
 			2130
 			60
 			85
 			90


595x595x381
 			6
 			2130
 			80
 			125
 			130

 			12
 			3400
 			80
 			125
 			130


595x595x500
 			6
 			3400
 			70
 			105
 			110

 			12
 			4250
 			70
 			105
 			110










Product Tags:

0.5um Pocket Air Filter

Ultra Fine 98% Pocket Air Filter

0.5um air filter bag

Ultra Fine 98% 0.5um Pocket Air Filter High Temperature Resistant Images

Inquiry Cart 0

Send your message to this supplier


*From:	Your email address is incorrect!
*To:	Xinxiang Risheng Filter Co., Ltd.
*Subject:	Subject is empty!
*Message:	For the best results, we recommend including the following details: -Self introduction -Required specifications -Inquire about price/MOQ Characters Remaining: (0/3000) Please enter 20 to 3000 characters to contact this supplier!

Media	Glass fiber
Pocket-type	Sewing bag,Ultrasonic bag
Frame	Aluminum/Galvanized steel/Stainless steel/Plastic
Filter Efficiency(EN779)	F5 F6 F7 F8 F9
Filter Efficiency(EN779)	F5 F6 F7 F8 F9
Max. Temperature	150℃
Max. Humidity	100%

Actual size	Number of bags(p)	Air volume (m³/h)	Initial resistance (Pa)			Final Resistance (Pa)
Actual size	Number of bags(p)	Air volume (m³/h)	F6	F7	F8	Final Resistance (Pa)
289x595x381	3	1070	80	125	130	2.5 times the initial resistance
289x595x381	6	1700	80	125	130
289x595x500	3	1700	70	105	110
289x595x500	6	2130	70	105	110
285x595x762	3	1700	60	85	90
285x595x762	6	2130	60	85	90
595x595x381	6	2130	80	125	130
595x595x381	12	3400	80	125	130
595x595x500	6	3400	70	105	110
595x595x500	12	4250	70	105	110
